XCMG Used Rotary Pile Drilling Rig XR280D Drilling Machine for Sale

XCMG Used Rotary Pile Drilling Rig XR280D Drilling Machine for Sale

Name: XCMG Used Rotary Pile Drilling Rig XR280D Drilling Machine for Sale
Brand: XCMG
SKU: 68621035
Price: 207709.00 USD
Availability: InStock

Get Latest Price

Model No.:68621035

Category:Rotary Drilling Rig

Price:207709

Original Price:207709

Images:7

Payment Type:T/T, L/C

Incoterm:FOB, CIF

Min. Order:1 unit

Transportation:Ocean

Port:Shanghai port, Qingdao port, Lianyungang Port

Product Description

Model No.:68621035

Category:Rotary Drilling Rig

Delivery:Shop Delivery

Delivery Amount:0

Brief:XCMG Used Rotary Pile Drilling Rig XR280D Drilling Machine for Sale | Brand: XCMG | Model: XR280D | Transport: Ocean | Port: Shanghai port,Qingdao port,Lianyungang port

XCMG Used Rotary Pile Drilling Rig XR280D Drilling Machine for Sale

XCMG XR280D Rotary Drilling Rig widely used in boring operation of bored concrete pile in foundation engineering of highway, railways, bridges, ports, docks and high-rise buildings.

The special hydraulic chassis for the rotating drill with extensible crawler is provided with the excellent stability and is convenient to transport. The imported turbo-supercharged engine(meeting EU-III standard) is powerful, and has sufficient power reserve, which can be operated in plateau. Its noise and emission meet the national standards. The constant power and the best output enable the complete machine to function at its best.

The patented parallelogram articulation mechanism can work in a large area. The drill mast, which is designed in box structure and made of the materials with high strength, has good rigidityand anti-distortion, guaranteeing the drilling accuracy. The hinge is provided with the bearing exempt from lubrication, and can work freely. The slag can be discharged in any angle due to 360 degree lifting and revolving.

The intellectual controlling system, CAN bus and PLC with self-intellectual property right are used, including the automatic and manual regulation of the perpendicularity of the drill mast, automatic display of the drilling depth, automatic rotation positioning control, and intellectual fault diagnosis control.

Drilling rig dimension in transport condition (L × W × H)		mm	17380×3500×3540
Weight of overall unit (standard configuration, excluding drilling tool)		t	84
Engine	Model		QSM11-C400
Engine	Rated power/speed	kw	298/(2200r/min)
Rotary drive	Max. torque	kn.m	280
Rotary drive	Rotational speed	r/min	6~22
Crowd cylinder	Max. Pushing force	kn	210
	Max. Pulling force	kn	220
	Max.stroke	mm	6000
Main winch	Max.pulling force	kn	260
Main winch	Max. single-rope speed	m/min	60
Auxiliary winch	Max.pulling force	kn	100
Auxiliary winch	Max. single-rope speed	m/min	65
Drilling mast	Left/right inclination of mast	°	4/4
Drilling mast	Front/back inclination of mast	°	5/15
Rotary table slewing angle		°	360
Traveling	Max. traveling speed of the overall unit	km/h	1.5
Traveling	Max. climbable gradient of the overall unit	%	35
Crawler	Width of crawler plate	mm	800
	External width of crawler (min.-max.)	mm	3500~4800
	Center distance between two longitudinal wheels of crawler	mm	5175
	Average ground pressure	kpa	102

OUR PRODUCTS

Used Hoisting Machinery

Used Excavator

Used Loader

Used Mining Machinery

FAQ

■ 1.What's the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the wearing parts and wearing parts. For engine, gearbox, hydraulic pump, distributor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

■ 2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professional institute.

■ 3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of construction machineries.

■ 4.Can you satisfy my special requirement?

As the manufacturer, XCMG will review the special requirement and recondition it as per request (if possible).

■ 5.What is acceptable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight. If any other questions, please feel free to contact us.
