XCMG Used Drilling Rig Machine XR320E Rotary Drilling Rig Price

XCMG Used Drilling Rig Machine XR320E Rotary Drilling Rig Price

Name: XCMG Used Drilling Rig Machine XR320E Rotary Drilling Rig Price
Brand: XCMG
SKU: 68622081
Price: 356111.00 USD
Availability: InStock

Get Latest Price

Model No.:68622081

Category:Rotary Drilling Rig

Price:356111

Original Price:356111

Images:7

Payment Type:T/T, L/C

Incoterm:FOB, CIF

Min. Order:1 unit

Transportation:Ocean

Port:Shanghai port, Qingdao port, Lianyungang Port

Product Description

Model No.:68622081

Category:Rotary Drilling Rig

Delivery:Shop Delivery

Delivery Amount:0

Brief:XCMG Used Drilling Rig Machine XR320E Rotary Drilling Rig Price | Brand: XCMG | Model: XR320E | Transport: Ocean | Port: Shanghai port,Qingdao port,Lianyungang port

XCMG Used Drilling Rig Machine XR320E Rotary Drilling Rig Price

It adopts dedicated hydraulic retractable crawler chassis and heavy slewing bearing and has high stability;

It adopts the luffing mechanism of large triangle form to ensure the stability ofconstruction of big holes and deep piles in hard formation;

It adopts the front-located single-rope main winch structure to greatly prolongthe service life of steel wire rope and lower the use cost;

According to specific working conditions, the users can select a corresponding gear of the Cummins turbo-supercharged engine with three gears, getting the drilling rig working as three engines;

Unit head can switch between Normal Mode and Rock Cracking Mode which are applicable for soil and rock excavation respectively, improving the efficiency;

Winch pressurization and sleeve drive are both available for selection to meet users' various demands;

It is equipped with a centralized lubrication system as standard configuration,maintenance is easier.


Engine
Model	VOLVO TAD1382VE--C428
Rated Power	315kW
Rotary Drive
Max.output torque	320kN.m
Rotary Speed	6-27r/min
Max.Drilling Diameter	2300mm
Max.Drilling Depth	61/94m
Crowd cylinder
Max.pull-down piston push
Max.pull-down piston pull
Max.pull-down piston stroke
Crowd Winch
Max.pull-down piston push
Max.pull-down piston pull
Max.pull-down piston stroke
Main Winch
Max.pulling force	340kN
Max.line speed	75m/min
Auxiliary Winch
Max.pulling force	100kN
Max.line speed
Mast Rake（Slide/forwards/backwards）
Undercarrige
Max.traveling speed
Max.grade ability
Min.clearance
Track shoe width	800mm
Distance between tracks	5175mm
Hydraulic system
Working pressure
Overall Drilling Weight	106t
Dimension	11000×4800×25510,mm
Working condition
Transporation condition

OUR PRODUCTS

Used Hoisting Machinery

Used Excavator

Used Loader

Used Mining Machinery

FAQ

■ 1.What's the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the wearing parts and wearing parts. For engine, gearbox, hydraulic pump, distributor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

■ 2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professional institute.

■ 3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of construction machineries.

■ 4.Can you satisfy my special requirement?

As the manufacturer, XCMG will review the special requirement and recondition it as per request (if possible).

■ 5.What is acceptable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight. If any other questions, please feel free to contact us.
