Name: XCMG XZ360E Horizontal Directional Drilling Equipment Price
Brand: XCMG
SKU: 68755670
Price: 56000.00 USD
Availability: InStock

Get Latest Price

Model No.:68755670

Category:Horizontal Directional Drill

Price:56000

Original Price:56000

Images:6

Payment Type:T/T, L/C

Incoterm:FOB, CIF

Min. Order:1 unit

Transportation:Ocean

Port:Shanghai port, Qingdao port, Lianyungang Port

Product Description

Model No.:68755670

Category:Horizontal Directional Drill

Delivery:Shop Delivery

Delivery Amount:0

Brief:XCMG XZ360E Horizontal Directional Drilling Equipment Price | Brand: XCMG | Model: XZ360E | Transport: Ocean | Port: Shanghai port,Qingdao port,Lianyungang port

XCMG XZ360E Horizontal Directional Drilling Equipment Price

Patented technology of power head floating and vise floating can greatly protect the drill pipe thread to increase the service life of the drill pipe.

High/low speed push-pull and rotation system in which the variable piston motor achieves the high/low push-pull speed of power head improves the ability to adapt to various working conditions and improves the construction efficiency of the drilling rig.

The configuration is flexible and diverse. The whole machine can be equipped with automatic (semi-automatic) pipe loader, double automatic anchoring device, mud antifreeze, mud cleaning device, etc. It can also be equipped with more environmentally friendly and energy-saving engine.

Description	Unit			Parameter value
Engine	Manufacturers			Dongfeng Cum s
	China III	Model		QSB5.9-C210
		Rated Power	kW /(r/min)	154 / 2200
	China II	Model		6BTAA5.9-C205
		Rated Power	kW /(r/min)	153/ 2200
Thrust-Pull	Type			Pinion and rack drive
	Max thrust-pull force		kN	320/320
	Max thrust-pull speed		m/min	22
Rotation	Type			Four motor
	Torque		N·m	12000
	Max spindle speed		r/min	0~140
Loader Crance	/			/
Max inclination angle	°			20
Pipe	Diameter × Length		mm×mm	Φ73×3000
Mud pump	Max Flow rate		L/min	320
	Max pressure		MPa	8
Weight	kg			10500

OUR PRODUCTS

Used Hoisting Machinery

Used Excavator

Used Loader

Used Mining Machinery

FAQ

■ 1.What's the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the wearing parts and wearing parts. For engine, gearbox, hydraulic pump, distributor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

■ 2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professional institute.

■ 3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of construction machineries.

■ 4.Can you satisfy my special requirement?

As the manufacturer, XCMG will review the special requirement and recondition it as per request (if possible).

■ 5.What is acceptable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight. If any other questions, please feel free to contact us.
