XCMG XZ450PLUS Horizontal Drill Rig for Sale

XCMG XZ450PLUS Horizontal Drill Rig for Sale

Name: XCMG XZ450PLUS Horizontal Drill Rig for Sale
Brand: XCMG
SKU: 68755656
Price: 83000.00 USD
Availability: InStock

Obtenir le dernier prix

Model No.:68755656

Category:Horizontal Directional Drill

Price:83000

Original Price:83000

Images:7

Type de paiement:T/T, L/C

Incoterm:FOB, CIF

Commande min.:1 unit

Transport:Ocean

Port:Shanghai port, Qingdao port, Lianyungang Port

Description du produit

Model No.:68755656

Category:Horizontal Directional Drill

Delivery:Shop Delivery

Delivery Amount:0

Brief:XCMG XZ450PLUS Horizontal Drill Rig for Sale | Brand: XCMG | Model: XZ450PLUS | Transport: Ocean | Port: Shanghai port,Qingdao port,Lianyungang port

XCMG XZ450PLUS Horizontal Drill Rig for Sale

Patented technology of power head floating and vise floating can greatly protect the drill pipe thread to increase the service life of the drill pipe. High/low speed push-pull and rotation system in which the variable piston motor achieves the high/low push-pull speed of power head improves the ability to adapt to various working conditions and improves the construction efficiency of the drilling rig.

The configuration is flexible and diverse. The whole machine can be equipped with automatic (semi-automatic) pipe loader, double automatic anchoring device, mud antifreeze, mud cleaning device, etc. It can also be equipped with more environmentally friendly and energy-saving engine.

Item		Unit	XZ450PLUS
Engine	Model		QSB8.3-C260
Engine	Rated power	Kw/r/min	194/2200
Thrust-Pull	Max pull/ thrust force	kN	960
Thrust-Pull	Max pull/ thrust speed	m/min	40
Rotation	Torque	N.m	27000
Rotation	Max spindle speed	r/min	135
Mud pump	Max flow rate	L/min	600
Mud pump	Max pressure	Mpa	10
Pipe	Diameter*Length	mm*m	4.5
Truck-mounted	Lifting weight	t	2
Truck-mounted	Loading capacity	t.m	4
Max inclination angle		°	20
Max backreamer diameter		mm	1200
Weight		t	13.5
Dimension		mm	750022802610

Produits recommandés

NOS PRODUITS

Used Hoisting Machinery

Used Excavator

Used Loader

Used Mining Machinery

FAQ

■ 1.What's the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the wearing parts and wearing parts. For engine, gearbox, hydraulic pump, distributor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

■ 2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professional institute.

■ 3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of construction machineries.

■ 4.Can you satisfy my special requirement?

As the manufacturer, XCMG will review the special requirement and recondition it as per request (if possible).

■ 5.What is acceptable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight. If any other questions, please feel free to contact us.
