2020 XCMG Used Concrete Boom Pump 10*4 HB67V in Stock

2020 XCMG Used Concrete Boom Pump 10*4 HB67V in Stock

Name: 2020 XCMG Used Concrete Boom Pump 10*4 HB67V in Stock
Brand: XCMG
SKU: 64694712
Price: 114300.00 USD
Availability: InStock

Get Latest Price

Model No.:64694712

Category:Concrete Pump Truck

Price:114300

Original Price:114300

Images:6

Payment Type:T/T, L/C

Incoterm:FOB, CIF

Min. Order:1 unit

Transportation:Ocean

Port:Shanghai port, Qingdao port, Lianyungang Port

Product Description

Model No.:64694712

Category:Concrete Pump Truck

Delivery:Shop Delivery

Delivery Amount:0

Brief:2020 XCMG Used Concrete Boom Pump 10*4 HB67V in Stock | Brand: XCMG | Model: HB67V | Transport: Ocean | Port: Shanghai port,Qingdao port,Lianyungang port

XCMG Used Concrete Boom Pump 10*4 HB67V with 66.1m Max.reach height in Stock

Concrete pumps truck HB67V is equipped with more efficient skirt valve pump technology, more stable reversing buffer technology, more reliable full hydraulic reversing technology. cement concrete pumps truck HB67V is equipped with chassis, which has dual circuit compressed air brake system, with air dryer, computer intelligent load sensing system and intelligent braking control system. cement concrete pumps truck HB67V adopts sitrak chassis, which complies with China 5 emission standard, featuring with powerful output, large torque, high efficiency, energy conservation and strong off-road performance.

Advantages and highlights:

1.Ultimately Safe Boom.

2. Lower Structure of High Rigidity.

3.Hydraulic System of Outstanding Performance.

4.Effectively reduce emissions with the reversing, vulnerability of longer life.

5.The pumping system adopts electric control reversing, reversing faster and the system impact smaller.

6.The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.

7. The adoption of new multi-section boom design optimized by bionic technology effectively reduces placing blind zone and better adapts to placing in high-rise and narrow space.

8. On the basis of the design concept of high rigidity structure, simulative calculation and testing of full-work-condition loading make chassis structure deformation smaller and overall work stability higher.

9. Based on laser guide, coaxial assembly makes piston head’s moving track more precise, with smaller resistance and higher efficiency.

10. Germany’s hydraulic technology quintessence truly realizes fully-hydraulic reversing, in which self-adaption control in fully-hydraulic closed-loop is realized, with no need for any electrical components, more effective, steadier and zero pollution.

Item		Unit	HB67V
Overall	Outline dimension	mm	1578025004000
Overall	Overall weight	kg	53000
Chassis	Model	-	Actros 5046E5
	Wheelbase	mm	2020+5180+1350+1450
	Max.power	kW	335
	Emission standard	-	China V
Pumping system	Theoretical	m³/h	170
	Concrete pumping pressure	MPa	8
	Theoretical pumping times	Times/min	21~23
	Delivery cylinder diameter x stroke	mm	φ260×2000
Placing boom	Reach height	m	66.1
	Reach depth	m	48.6
	Slewing radius	m	60.9
	Slewing angle	°	±270
Others	Transfer tuble	-	Rock valve

OUR PRODUCTS

Used Hoisting Machinery

Used Excavator

Used Loader

Used Mining Machinery

FAQ

■ 1.What's the warranty policy for XCMG reconditioned machines?

The warranty policy does not cover the wearing parts and wearing parts. For engine, gearbox, hydraulic pump, distributor valve and electric system, the warranty period will be 3 months or 500 working hours whichever comes first. If there is any problem within warranty period, XCMG will provide solutions accordingly.

■ 2.How about the quality of your machine?

The procedure of recondition is taking the same criterion of brand new XCMG machines, therefore, quality of machines will be guaranteed. They are ready to work for you and XCMG will provide test report from professional institute.

■ 3.Are you the original manufacturer?

Yes! XCMG is leading construction machinery industry in China and XCMG can provide a complete range of construction machineries.

■ 4.Can you satisfy my special requirement?

As the manufacturer, XCMG will review the special requirement and recondition it as per request (if possible).

■ 5.What is acceptable payment terms?

Usually XCMG will accept T/T before shipment or 100% Letter of Credit at sight. If any other questions, please feel free to contact us.
